AS-2TC Amplifier Module
About the product
Board designed to amplify a signal to equipment with a current loop 4-20mA or 0-10V. For 35mm DIN rail.
Operating temperature range Min: -10ºC / Max: +40ºC. Power supply: 24VDC.
Input signal range: 0 – 30 mV.
Output signal: 0-10V / 4-20mA.
Height 83mm. Width 70mm. Depth 67mm.
Manufacturer
About the product
Board designed to amplify a signal to equipment with a current loop 4-20mA or 0-10V. For 35mm DIN rail.
Operating temperature range Min: -10ºC / Max: +40ºC. Power supply: 24VDC.
Input signal range: 0 – 30 mV.
Output signal: 0-10V / 4-20mA.
Height 83mm. Width 70mm. Depth 67mm.
