High capacity standard reference force transducer tension and compression 5105-ISO

About the product

Standard reference force transducers specially designed according to the ISO 376 standard (classes 1, 0.5 and 00).

Standard reference force transducer specially designed according to the norm ISO 376(1) (Class "1", "05" and "00").
- Broad range of capacities (up to 30 MN)
- Complete range of load accessories
- Protection: IP65
- Material: Nickel plated alloy steel
- Options :
o digital output RS-232C or RS-485
o custom made dimensions
o ASTM E74 compliant
The SENSY's load cell 5105-ISO is perfectly designed to the following applications :
- Control of testing machines according to ISO7500
Note: This standard covers the calibration of standard force measurement instruments used for the static verification of uniaxial testing machines. it describes classifying procedures for the instruments.
CAPACITIES :
5105 : (10) - (15) - 20 - 30 - 50 - (75) - 100 - (150) - 200 - 300 - 500 kN
(0.75) - 1 - 1.5 - 2 - 3 - 5 - 7.5 - 10 - 15 - 20 - 30 MN
