Strain measurement with subsea load cell

  • mesure-des-efforts-de-traction-au-travers-d-un-capteur-de-force-submersible-1.png
  • mesure-des-efforts-de-traction-au-travers-d-un-capteur-de-force-submersible-2.png
  • mesure-des-efforts-de-traction-au-travers-d-un-capteur-de-force-submersible-3.png

About the product

Consulting on the design and production of subsea force sensors for military applications. These sensors measure and display the tension forces applied to slings designed to hold a submarine launch pad in place.

1st step: Description of customer requirements

Features:

Capacity: 200 kN
Permissible overload: 300 kN
Accuracy: 0.25%
Resolution: 0.1 kN
Dimensions: According to the following sketch
Protection class : IP68 10 bars (sea water)
Material: Stainless steel for marine use
Display: Display behind a glass
Supply : Battery
Operating autonomy: 25 hours
Autonomy off: 1500 hours
On/off: By button accessible from outside
No tare loss if power off

2nd step: Design (3D analysis + approval drawing for the customer before machining)

These features are in accordance with those requested:

Dimensions: According to the following drawing
Display: 4.5 digits (10 mm)
Power : 9V alkaline battery (pp3)
On/off button: ILS lever and switch
Material: Stainless steel close to 316L
Weight: 33 kg
Calibration: In 10 points
Delivery time for: 8 to 10 weeks after receipt of approval

Step 3: Manufacturing
